Canon FD 85 1.2 L

Lens Resized

Data

  • Focal Length: 85mm
  • Aperture: 1.2 – 22.0
  • Aperture Blades: 8
  • min. Focusdistance: 0.9m
  • Filter size: 72mm
  • Hood: BT-72
  • Length x max diameter: 78mm x 81mm
  • Weight: 680gr

Test Conditions

  • Used Camera: Sony A7 (Fullframe)
  • Setting: Tripod, 2s timer
  • FX: None




Test

Sharpness



F 1.2

F1.2 Resized

F 2.0

F2.0 Resized

F 2.8

F2.8 Resized

F 4.0

F4.0 Resized

F 5.6

F5.6 Resized

F 8.0

F8.0 Resized

At 1.2 you’ll get a soft image. But the purple fringing carries more weight. Every hard and contrasty (or metallic) edge will glow purple. At F 2.0 you see a heavy image quality improvment (sorry for the jogger), the PF and the softness alsmost vanish. At F 5.6 it’s sharp from edge to edge.

Distortion

Corrected

DSC00452_m_Canon FD 85 1.2 L_corrected

Uncorrected

DSC00452_m_Canon FD 85 1.2 L-2

LR Settings

Bildschirmfoto 2015-02-06 um 16.09.19

Bokeh

F 1.2 Corner (edited image)

DSC00037_m_

F 1.2 (edited image)

DSC00426_m_Canon FD 85 1.2 L

F 1.2 (edited image)

DSC00440_m_

The Bokeh is smooth and nearly free of chromatic abberations. This lens is legendary for its possibilty to isolate the subject from the background while containing a plastic look. I’d approve that. The onionrings as you see them in the first picture are annoying, be careful concerning highlights in the background at low distances and open apertures. As you can see the highlights are transforming from circles in the center to cateyes in the corners.

Mechanics

The focusring is hard-steering. I don’t think this only affects my lens, since the heavy frontelement is moving while focusing i’d assume it’s because of the mass you have to move. From closest focus to infinity you can turn the focusring about 100° that’s really comfortable because at 1.2 you just have submm focuslayers.

Conclusion

This lens is heavy and bulky but it’s center sharp at 1.2 and definetely my best lens for Portraits (especially heads). The Bokeh slightly swirls wideopen which creates a center focusing look. Purple fringing could be extreme but is easy to fix. The onionrings in the highlight bubbles are much heavier if you don’t like them.

A hood is highly recommended! Lateral light always results in heavy flares. The BT-72 got really rare and since i didn’t want to pay more than 50€ for a sun shade i bought a rubber sun shade which works too.
